CANON CMOS SENSORS FROM CANON USA, IMAGING SOLUTIONS GROUP

Canon CMOS sensors push the boundaries of what’s possible in industrial vision.

For industrial, machine vision, medical, and scientific applications, CMOS sensors from Canon offer camera OEMs and end users expanded possibilities with the latest technology. Whether its exceptionally high pixel counts in a compact design, or enormous pixel sizes for high sensitivity, Canon’s pixel-level innovations deliver entirely unique performance. Leverage renowned Canon quality for ultra-high resolution, ultra-high sensitivity, or low power consumption in your vision application and see what’s possible with Canon CMOS sensors.

The Imaging Solutions Group (ISG) within Canon USA Inc. incorporates current and future Canon technologies into new products and solutions, including innovative CMOS sensors that overcome major technical barriers in the vision industry.

HOT PRODUCTS

CMOS Sensor Family CMOS Sensor Family

For several decades Canon, has been developing and manufacturing advanced sensors with state-of-the-art technologies for exclusive use in Canon products. The sensors are a driving force behind many successful products, from consumer products up to high-end business and industrial solutions.

19 µm Pixel Single CMOS Sensor With Enhanced NIR Detection: 35MMFHDXSB 19 µm Pixel Single CMOS Sensor With Enhanced NIR Detection: 35MMFHDXSB

Canon’s 35MMFHDXSB sensors are designed with deeper wells, resulting in an almost 45% increase in quantum efficiency (QE) at 800 nm verses the standard 19 µm pixel size sensor. Featuring 19µm pixel sizes available in monochrome (35MMFHDXSBM) or with a specialized RGB-NIR color filter array (35MMFHDXSBI), these CMOS sensors allow for expanded possibilities in a wide range of applications.

250 MP Resolution CMOS Sensor: 2U250MRXS 250 MP Resolution CMOS Sensor: 2U250MRXS

Canon’s 2U250MRXS CMOS sensor offers 250 MP resolution capable of capturing detail 125 times greater than in full HD resolution at a fast frame rate of 5 FPS. This APS-H format sensor leverages a square pixel arrangement of 1.5 µm x 1.5 µm pixels with progressive reading of 1.5 µm pixels across 16 digital output channels to handle the enormous amount of image data created by roughly 250 million effective pixels.

120 Megapixel CMOS Sensor: 120MXS 120 Megapixel CMOS Sensor: 120MXS

The 120MXS 120 Megapixel CMOS Sensor has a pixel count equivalent to the approximate number of photoreceptor cells in the human eye. Recording capabilities at approximately 60x the full HD resolution of 1920 x 1080 are made possible by parallel signal processing, which reads signals at a high speed from multiple pixels.

19 μm FHD CMOS Sensor: 35MMFHDXSCA 19 μm FHD CMOS Sensor: 35MMFHDXSCA

The 35MMFHDXSCA 19 μm FHD CMOS Sensor features high-sensitivity, and low-noise imaging performance for the capture of full HD video in exceptionally low light environments. The larger pixel size of 19 μm x 19 μm alongside proprietary device design technologies helps to achieve higher sensitivity and an increased well depth. This 35 mm CMOS sensor provides the largest 16:9 imaging area possible when used with Canon EF lenses.

5 Megapixel Global Shutter CMOS Sensor: 3U5MGXS 5 Megapixel Global Shutter CMOS Sensor: 3U5MGXS

The 3U5MGXS is a 5 Megapixel Global Shutter CMOS Sensor equipped with a global shutter that exposes all of the sensors’ pixels at the same time. This global shutter image sensor employs a new pixel design introducing new drive readout and light guiding technologies significantly reducing noise, and contributing to a wide dynamic range with a power consumption of 500 mW.

INDUSTRIES & APPLICATIONS

Astronomy Astronomy

Canon CMOS Sensors give astronomers the high-performance imaging capabilities they need to explore more of the universe.

Automotive Industry Automotive Industry

Featuring ultra-high pixel counts, large pixel sizes, compact designs, and global shutters, Canon’s new line of CMOS sensors for automotive applications offer opportunities for your innovations.

Industrial Camera OEMs Industrial Camera OEMs

Canon CMOS sensors put innovation within reach, enabling industrial camera OEMs to take on the tough application challenges of end users and realize their cutting-edge products.

Defense Defense

Canon CMOS sensors offer unique performance for next-generation defense solutions.

Document Scanning And Archiving Document Scanning And Archiving

CMOS sensors from Canon deliver the high image quality needed to enhance the accuracy and efficiency of document scanners for inspection and archiving.

Food And Beverage Food And Beverage

Canon CMOS Sensors offer new capabilities for innovative imaging solutions for the food and beverage industries.

Intelligent Transportation Systems Intelligent Transportation Systems

To improve mobility, sustainability, and productivity, Canon CMOS sensors with pixel-level innovations in sensor design deliver unparalleled imaging performance for effective, reliable intelligent transportation solutions.

Aerial Mapping Aerial Mapping

Canon’s new line of CMOS sensors delivers innovative performance for greater mapping capabilities.

Border Security And Patrol Border Security And Patrol

Canon CMOS sensors deliver unique performance capabilities to see more in border security and patrol.

Flat Panel Display Inspection Flat Panel Display Inspection

Canon CMOS sensors offer best-in-class performance when detecting minute defects during the high-value flat panel display inspection process.

High End Surveillance High End Surveillance

Canon sensors offer advanced surveillance capabilities and unique performance for accurate and reliable imaging in a wide range of settings.

Microscopy Microscopy

Canon CMOS sensors deliver the performance capabilities needed for the unique challenges of microscopy.

Unmanned Aerial Vehicles Unmanned Aerial Vehicles

CMOS sensors from Canon have been engineered to meet the demanding requirements needed for optimal UAV performance, empowering OEMs to develop market-leading UAV solutions.

CONTACT INFORMATION

Canon USA Imaging Solutions Group

1 Canon Park

Melville, NY 11747

UNITED STATES

Phone: 1-800-OK-CANON

Contact: Michael Simmons

FEATURED NEWS

FEATURED ARTICLES

  • CMOS Image Sensors: System Engineering Considerations For Selecting 100+ MP Imaging Sensors
    CMOS Image Sensors: System Engineering Considerations For Selecting 100+ MP Imaging Sensors

    While digital CCD image sensors have been around for decades, CMOS Image Sensor (CIS) technologies become more advanced and capable, they are becoming the design choice for many applications. Today’s advanced CISs are available with more than 100MP on the commercial market. This white paper presents important considerations to make in the design selection phase of high resolution CIS devices, especially in regard to size, weight, power, and cost (SWaP-C).

  • Why Choose Canon Industrial Sensors?
    Why Choose Canon Industrial Sensors?

    CMOS sensors from Canon feature proprietary innovations at the pixel-level that translate into industry-leading performance in advanced industrial, medical, and scientific applications.

  • Technology Advances Lead To CMOS Sensor With Record Resolution
    Technology Advances Lead To CMOS Sensor With Record Resolution

    In the past decade, CMOS sensors have emerged as the imaging technology of choice for many applications. Today, they are not only used in almost all cell phones and mobile devices, but are also commonly found in industrial and medical cameras.

  • Considering High Dynamic Range Global Shutter CMOS Sensors
    Considering High Dynamic Range Global Shutter CMOS Sensors

    CMOS Image sensors with a global shutter are ideal for a variety of applications, including factory automation, unmanned aerial vehicles, and automobile driver-assistance systems.

  • Advances In CMOS Image Sensors And Associated Processing: Part 2
    Advances In CMOS Image Sensors And Associated Processing: Part 2

    Part 2 of the series describing advancements in CMOS sensors and processing focuses on a new Super 35 mm CMOS image sensor that is specifically developed to support origination of high dynamic range (HDR) motion imagery.

  • Advances In CMOS Image Sensors And Associated Processing: Part 1
    Advances In CMOS Image Sensors And Associated Processing: Part 1

    New Canon technology has exploited a large 35 mm Full Frame CMOS image sensor with spatial sampling of 1920 (H) x 1080 (V) to acquire a distinctively large photosite of 19 um x 19 um, which enabled development of an HD camera with unprecedented sensitivity.
