New System Configurator For Inverted Microscopes & XY Motorized Stages, What To Use When

Learn how to combine the best micrometer or nanometer class motorized stages, piezo stages, and sample holders while achieving requirements of high velocity and long term stability.

Auburn, MA – To answer the demand for an integrated inverted microscope positioning system that must match perfectly, PI (Physik Instrumente), a leader in precision motion control and nanopositioning solutions, has released an interactive brochure to aid in building the system by beginning with a fine positioner and/or a sample holder. Stages with piezo nanopositioning are incorporated to satisfy application requirements, such as low-profile, vibration-free dynamic range, and XY / Z positioning.

Precision Positioning is the Key Element in High Resolution Microscopy
Precision positioning of the sample is a must for accurate results when using an inverted microscope. PI provides options with high stability motorized stages for long travel ranges with wide dynamic range, manual sample positioning / prepositioning, piezo scanning stages, and z-positioning / vertical stages to move the sample or the objective. PI solutions include:

• High Stability, Ceramic Linear Motor-Driven, Long Travel XY Stage System, with Controller and Joystick
• XYZ Nanopositioning Stage, for Super-Resolution Microscopy, P-545 PInano with Digital Controller and Software
• Piezo Z-Insert, for fast Nano-Focus of Samples, P-736 PInano Stage XY Stage with Digital Controller and Software

Download Configurator Brochure»

Nanopositioning for Microscopy»

Working with You
PI’s in-house engineered systems and components have enabled customers around the world to increase their productivity and technological advantage for 5 decades. With a large basis of standard precision motion products and proven methodologies, PI is in the position to quickly modify existing designs or provide a fully customized OEM solution to fit the exact requirements of your application from the whole motion range from finger-tip sized nano-positioners to large scale stages with long travel ranges, through a plethora of different drives and guiding systems.

About PI

PI is a privately held company that designs and manufactures world-class precision motion and automation systems including air bearings, hexapods and piezo drives at locations in North America, Europe, and Asia. The company was founded 5 decades ago and today employs more than 1300 people worldwide. PI’s customers are leaders in high-tech industries and research institutes in fields such as photonics, life-sciences, semiconductors and aerospace.
