FST-Series Multi-Channel Fiber-Optic Test Sets
Source: Electro-Optical Systems Inc.
The FST-series multi-channel test sets are designed for universal applications such as laser diode life testing, burn-in testing or others requiring continuous monitoring of multiple channel outputs.
The FST-series multi-channel test sets are designed for universal applications such as laser diode life testing, burn-in testing or others requiring continuous monitoring of multiple channel outputs. The basic module, the FST- 16 consists of 16 FO- connectorized photodiodes, either silicon or InGaAs depending on wavelength of interest, and 16 individual transimpedance amplifiers. The internal data acquisition system includes analog multiplexing, sample / hold, and 12 bit A / D conversion at a 10uS sampling rate. Output data is available in serial or parallel format, with logic output lines for data ready / MUX channel status. The unit is packaged in a bench-type instrument housing or rack-mount enclosure. 32-, 48-, and 64- channel versions are also available.
General Specifications:
Number of Channels: 16 (32, 48, 64 optional)
Detector Type: 1 mm dia Si or InGaAs photodiode standard accomodates all size fibers
Amplifier: Fixed gain transimpedance user can specify expected power levels
FO connector: User specified- ST, FC, SMA available
Resolution: 12-bit A / D
Sampling Rate: 10uS
Output: Serial, Parallel
Housing: 8" x 3" x 8" instrument case (16 channel) - 19" rack mount available
Power: 120/240 VAC
Electro-Optical Systems Inc., 1039 W. Bridge St., Phoenixville, PA 19460. Tel: 610-935-5838; Fax: 610-935-8548.
